Bently Nevada 330104-00-08-10-01-CN 3300 XL 8 mm Proximity Probe
Product Overview
This 330104-00-08-10-01-CN probe is part of the Bently Nevada 3300 XL 8 mm series. It is used for accurate, non-contact vibration and position measurements in rotating machinery. Made in the U.S.A, it is built for industrial reliability and performance.
Technical Specifications
- Measuring Range: Typically ±2 mm dynamic range
- Accuracy: Optimized for AISI 4140 steel targets
- Output Signal: Voltage signal proportional to distance
- Working Temperature: +18°C to +27°C typical (probe only: -35°C to +177°C)
- Power Supply: -17.5 Vdc to -26 Vdc
- DC Resistance (1.0 m cable): 7.59 Ω ± 0.50
- Output Resistance: 50 Ω
- Input: Compatible with 3300 XL 8 mm and 5 mm extension cables
Material Details
- Probe Tip: Polyphenylene sulfide (PPS)
- Probe Case: AISI 303 or 304 stainless steel
- Seal: Viton O-ring to seal pressure at the tip
Full Model Code Breakdown
- 330104: 3300 XL 8 mm Probe
- 00: 0 mm Unthreaded Length
- 08: 80 mm Overall Case Length
- 10: 1.0 meter Total Length (cable + probe)
- 01: Miniature ClickLoc connector with protector, standard cable
- CN: Country-specific agency approval
Installation Guidelines
Install with a standard mounting bracket. Align probe tip gap to 1.27 mm from the shaft. Ensure the cable route avoids sharp bends. Follow Bently Nevada’s drawing 140979 for non-incendive setup.
Compatibility
Fully compatible with 3300 XL Proximitor Sensors and extension cables. Use with AISI 4140 steel targets for rated performance.
Package Includes
- 1 × 330104-00-08-10-01-CN Proximity Probe
- Protective Connector Cap
- Factory Packaging (No certificate)
Warranty and Delivery
- 12-Month Warranty from shipment date
- Express shipping via FedEx, UPS, or DHL
