Bently Nevada 3300 XL 8mm Proximity Probe System
Key Technical Specifications (330104-05-10-10-02-CN )
Measure vibration and position in machines
- Linear Range: 0.25mm to 2.54mm
- System Accuracy: ±1% full scale
- Frequency Response: 0 to 10 kHz
- Output Signal: -10V to -2V DC voltage
- Operating Temperature: -40°C to +150°C
- Temperature Drift: 0.05%/°C
- Ingress Protection: IP67 rated
Model Breakdown
330104-05-10-10-02-CN
- 330104: 8mm Probe with M10x1 thread
- 05: Unthreaded length 5mm
- 10: Case length 100mm
- 10: Cable length 1.0 meter
- 02: Mini coaxial ClickLoc connector
- CN: Country specific approvals
Shipping & Support
Global delivery options
- Fast shipping: FedEx, UPS, DHL
- 12-month product warranty
- 24/7 technical support
- In stock for immediate dispatch
