With Armor | 3300 XL 8mm Proximity Probe 330104-00-08-10-02-CN

Bently Nevada 330104-00-08-10-02-CN 3300 XL 8mm Proximity Probes

Model Suffix Breakdown

330104: 3300 XL 8 mm Probe, M10 x 1 thread, with armor

-00 (Unthreaded Length: 0mm)

-08 (Case Length: 80mm)

-10 (Total Length: 1m)

-02 (Mini Coaxial Connector)

-CN (Country Approval)

Key Technical Specifications

• Measurement Range: 0-2mm (non-contact)
• Accuracy: ±0.01mm (calibrated with AISI 4140 steel target)
• Output Signal: -2V to -22V (50Ω output resistance)
• Operating Temp: 18°C-27°C (standard environment)
• Probe Resistance: 7.59±0.50Ω (1m cable length)
• Power Requirement: -17.5Vdc to -26Vdc (max 12mA)

Installation Guide

1. Clean target surface (AISI 4140 steel recommended)
2. Adjust probe gap to 1.27mm (50 mils)
3. Check Viton® O-ring seal condition
4. Connect 3300 series extension cable (model-matched)

System Compatibility

Only compatible with 3300 series 5mm/8mm probes and matched extension cables; accuracy applies to AISI 4140 steel target calibration only.

Industrial Applications

Suitable for vibration monitoring of rotating machinery (pumps, motors, turbines). Solves issues of wear in contact sensors and unstable signals in high-temp environments, ensuring continuous operation.

Packaging & Shipping

Package includes: Probe unit, 1m standard cable, installation manual, O-ring seal (no certificates/warranty docs)
Shipping methods: FedEx, UPS, DHL
