K-LB-1.6: Ultra-Compact Voltage Guardian
Single-channel surge defender for critical 6V systems. 20kA lightning protection with 500V isolation and auto-reset technology.
Technical Shield Matrix
| Critical Parameter | Performance Value |
| Lightning Strike Absorption | 20kA (8/20µs) |
| Isolation Strength | 500V DC breakdown |
| Response Speed | 1 nanosecond |
| Signal Purity | ≤0.3Ω resistance |
| Environmental Toughness | -30°C to 80°C operation |
Certified Safety Shield
ATEX Certified
II 2G Ex ia IIC T6
II 2G Ex ia IIC T6
IECEx Approved
BAS 14.0010X
BAS 14.0010X
IP20 Rated
Dust protected
Dust protected
Installation Blueprint
- Mount on 35mm DIN rail (EN 60715)
- Connect field device → Terminals 1-2
- Connect control system → Terminals 7-8
- Establish solid earth connection
- Verify 500V isolation integrity
Industry-Specific Protections
- 🌱 Vertical farm climate sensors
- 🏭 Pharmaceutical bioreactors
- ⚡ Substation battery monitors
- 🚢 Marine navigation equipment
- 📡 5G tower backup systems
- 🔬 Research lab spectrometers
Technical Specifications
- Voltage Range: ≤6V DC
- Current Capacity: ≤250mA
- Leakage Current: ≤10µA
- Clamping Voltage: ≤12V
- Bandwidth: ≥40kHz
- Dimensions: 12.5x114x110mm
Shipping & Support
| Delivery | FedEx/UPS/DHL (2-3 days) |
| Package | Barrier, DIN clip, manual |
| Warranty | 12 months |
| Weight | 100g (ultra-light) |
Maintenance Protocol
Annual Check: Ground connection resistance
Replace After: 5+ surge events
Environment: Avoid condensation formation
Lifespan: 10+ years in controlled environments
Expert Q&A
Q: Difference from 1.6G model?
A: Higher 500V isolation vs standard protection
Q: Suitable for outdoor use?
A: Indoor only (IP20 rating)
Q: Minimum voltage systems?
A: Protects 3.3V-6V circuits
