IC695MDL664 GE Fanuc PACSystem RX3i Digital Input Module

GE Fanuc IC695MDL664 Smart Digital Input Module

Description

16-point 24V DC input module from GE Intelligent Platforms. Part of the RX3i PACSystems series. Perfect for industrial automation with two isolated groups (8 inputs each). Works with sensors like limit switches and pushbuttons. Features LED status indicators and automatic terminal block detection.

Technical Data

Industrial Pain Points Solved

• Problem: Machine downtime from wiring faults
  Solution: LED alerts for terminal block loss/power failures
• Problem: Voltage fluctuations damaging inputs
  Solution: Wide 18-32V DC operating range
• Problem: Complex troubleshooting
  Solution: Per-group isolation and status LEDs

Installation Guide

• Fits any RX3i PLC I/O slot
• Connect field devices to spring/box terminals
• Ensure 24V DC power to each group
• Check S1/S2 LEDs for field power status

Compatibility

• Systems: RX3i PACSystems
• Terminals: IC695TBS008 (spring) / IC695TBT008 (box)
• Devices: Limit switches, proximity sensors, pushbuttons

Packaging Includes

• IC695MDL664 Input Module ×1
• Installation manual

Shipping

Global delivery via FedEx, UPS, DHL. Tracking provided.

FAQs

Q: Can I use 12V sensors?
A: No. Requires 18-32V DC input signals.

Q: Are terminal blocks included?
A: No. Order separately: IC695TBS008 (spring) or IC695TBT008 (box).

Q: How are inputs grouped?
A: Two isolated groups (inputs 1-8 and 9-16). Each has separate common connection.
