IC695CPU310 GE Fanuc 300MHz CPU Module PACSystem RX3i

IC695CPU310 PACSystems RX3i Processor – High-Speed Industrial Automation

Description

The GE Fanuc / Emerson Automation IC695CPU310 is a rugged Programmable Automation Controller (PAC) with 300MHz processing power and 10MB dual memory. Perfect for demanding industrial applications requiring fast scan times (0.195ms/1000 instructions) and flexible programming (ST, LD, FBD, C). Supports Modbus RTU and legacy Series 90-30 I/O migration.

Technical Data

• Brand: GE Fanuc / Emerson Automation
• Model: IC695CPU310
• Series: PACSystems RX3i
• Processor: 300MHz Intel Celeron M
• Memory: 10MB RAM + 10MB non-volatile
• Scan Time: 0.195ms per 1000 Boolean instructions
• Ports: 2x serial (RS232/RS485)
• Protocols: Modbus RTU slave, SNP, Serial I/O
• Power: 1.25A @3.3V DC, 1A @5V DC
• Temperature Range: 0°C to 60°C

Key Features

• ⚡ Fast Execution: Handles 512 program blocks (128KB each)
• 🔄 Compatibility: Works with RX3i & Series 90-30 backplanes
• 📡 Communication: Dual serial ports + Ethernet via IC695ETM001
• 🔋 Battery Options: Supports IC695ACC302/IC698ACC701

Installation Guide

•  Compatible backplanes: IC695CHS016 (16-slot) or IC695CHS012 (12-slot)
•  Connect via PCI slots for high-speed data transfer
•  Firmware upgradable for future features

Diagnostics & Maintenance

•  LED status indicators for quick troubleshooting
•  Use Proficy Machine Edition software for diagnostics
•  Replace batteries every 2-3 years (typical)

Packaging

•  1x IC695CPU310 Processor Module
• Shipping: FedEx/UPS/DHL (2-5 business days)

FAQ

Q: Does this support Ethernet?
A: Yes, when paired with IC695ETM001 module.

Q: Maximum I/O capacity?
A: Supports up to 32K discrete I/O points and 32K analog words.

Q: Warranty period?
A: 12 months from shipment date.
