IC695ALG616 PACSystem RX3i Analog Input Module
High-density analog input module with 16 single-ended or 8 differential channels. Supports voltage/current signals for industrial automation systems.
Technical Specifications
- Brand: Emerson (ex GE Fanuc)
- Model: IC695ALG616
- Voltage Range: ±10VDC, 0-10VDC, ±5VDC, 0-5VDC, 1-5VDC
- Current Range: 0-20mA, 4-20mA, ±20mA
- Resolution: 24-bit → IEEE 32-bit float/16-bit int
- Input Impedance: >100kΩ (voltage), 249Ω (current)
- Operating Temp: 0°C to 60°C (32°F to 140°F)
- Response Time: 1ms per channel
- Power: 3.3V@450mA + 5V@600mA
Installation & Compatibility
- Hot-swappable in RX3i Universal Backplane
- No jumpers/DIP switches needed
- Configurable via Proficy Machine Edition (PME)
- Compatible with all RX3i CPU models
Packaging & Support
- Module
- 12-month warranty
- Global shipping: FedEx/UPS/DHL
FAQ
Q: What’s the sampling rate per channel?
A: 50k samples/sec with 24-bit ADC conversion
Q: Can I mix voltage and current inputs?
A: Yes, each channel is independently configurable
Q: Is external signal conditioning needed?
A: No, direct connection for listed ranges
Comparison with Similar Modules
| Model | Channels | Resolution | Isolation | Key Advantage |
|---|---|---|---|---|
| IC695ALG412 | 4 | 16-bit | No | Basic 4-channel |
| IC695ALG600 | 8 SE / 4 Diff | 14-bit | No | Cost-effective |
| IC695ALG616 | 16 SE / 8 Diff | 24-bit | No | High-density precision |
