GE Fanuc IC694ALG391 2-Channel Analog Output Module
Precision control for small-scale automation. This compact module converts digital signals to analog currents for your RX3i PacSystem. Perfect for targeted process control.
KEY FEATURES
- 2 dedicated output channels for precise control
- Simple jumper configuration between 0-20mA/4-20mA
- Visual green “Module OK” light for instant status check
- Works with Series 90-30 and RX3i backplanes
TECHNICAL SPECS
- Brand: GE Fanuc
- Model: IC694ALG391
- Output Type: Analog current
- Channels: 2 isolated
- Signal Ranges: 0-20mA or 4-20mA
- Resolution: 12-bit (0.005mA precision)
- 5V Load Capacity: 30mA / 0.15W max
- 24V Load Capacity: 215mA / 5.16W max
- Compatible Systems: RX3i PacSystems, Series 90-30
POWER WARNING
Never install or remove with power on. Not hot-swappable. Turn off main power first to prevent damage or injury.
PACKAGE INCLUDES
- IC694ALG391 output module
- Quick-start guide (digital)
SUPPORT & DELIVERY
- 12-month warranty
- Worldwide shipping via FedEx, UPS, DHL
- Tracking number provided
COMMON QUESTIONS
Q: How many devices can this module control?
A: Controls 2 devices simultaneously with independent signals.
Q: Can I use both output types at once?
A: Yes! Configure each channel separately as 0-20mA or 4-20mA.
Q: What does the green LED indicate?
A: The “Module OK” light confirms proper power and operation.
Q: Is external power needed?
A: Runs on PLC backplane power – no extra supply required.
