Emerson PACSystem RX3i High-Density Analog Input – IC694ALG232
16-channel voltage input module with advanced diagnostics for industrial automation. Hot-swappable design simplifies maintenance in critical systems.
Core Technical Specifications
- Brand: Emerson (formerly GE Fanuc)
- Model: IC694ALG232
- Input Ranges: 0-10V / ±10V
- Channels: 16 single-ended or 8 differential
- Resolution: 0.3125mV/count
- Update Rate: 3ms (differential) / 5ms (single)
- Power: 112mA @ 5VDC
- Isolation: 250V AC continuous
- Temp Range: 0°C to 60°C
Installation Guide
- Hot-Swapping: Supported (live insertion/removal)
- Power Requirements:
- Universal backplane: External 24VDC
- Expansion backplane: Backplane power
- Impedance: >1MΩ (diff) / >500kΩ (single)
Compatibility
Works with all PACSystem RX3i CPUs. Requires RX3i backplane (universal or expansion).
Package & Shipping
- IC694ALG232 module
- 12-month warranty
- Shipping: FedEx/UPS/DHL global
- Lead Time: 3-5 business days
FAQ
Q: Can I mix input types?
A: All channels same range – configurable per installation
Q: Filter response difference?
A: 23Hz (single-end) vs 38Hz (differential)
Q: Maximum wiring distance?
A: 100m (328ft) with shielded cable
Q: Cold temperature operation?
A: Minimum 0°C – not for sub-zero environments
