IC693CPU311 GE Fanuc Single Slot CPU Module Series 90-30

GE Fanuc IC693CPU311 PLC Baseplate with Embedded CPU

Description

This 5-slot PLC baseplate has a built-in CPU for compact control systems. Made by GE Fanuc (now Emerson Automation), it fits Series 90-30 racks. The embedded 80188 CPU runs at 10 MHz and handles 160 digital I/O points plus analog signals. Perfect for space-limited industrial setups needing reliable automation.

Technical Data

• Brand: GE Fanuc / Emerson
• Model: IC693CPU311 (Series 90-30)
• Memory: 6KB user program
• I/O Capacity: 160 DI / 160 DO / 64 AI / 32 AO
• Speed: 18ms per 1K logic
• Port: 1 SNP/SNP-X slave via power supply
• Temp Range: 0°C to 60°C (32°F to 140°F)
• Power: 410mA @ 5VDC

Installation Guide

Mount in clean, vibration-free area. Use DIN rail or panel screws. Connect power supply to port slot. Allow 50mm clearance for heat. Ground all modules properly.

Compatibility Notes

Works with Series 90-30 I/O modules. Not compatible with PCM/CCM devices. Supports RAM, EPROM, EEPROM memory. Use with IC693/IC694 power supplies only.

Packaging List

• IC693CPU311 baseplate unit
• Terminal labels

Shipping

Global delivery via FedEx, UPS, DHL. Tracking provided. Ships in 1-3 business days.

FAQ

Q: Does this support Ethernet?
A: Requires optional GCM module

Q: Is real-time clock included?
A: No, lacks battery-backed clock

Q: Can I expand beyond 5 slots?
A: No expansion capability
