GE Fanuc PACSystems Rx3i IC695ALG608 Analog Input Module

IC695ALG608 RX3i Analog Input Module – High-Density Precision

8-channel flexible input with 24-bit resolution. Supports voltage (±10V) and current (4-20mA) signals in single-ended/differential modes. Ideal for complex process monitoring.

Advanced Specifications

• Brand: GE IP (Emerson)
• Model: IC695ALG608
• Series: PACSystem RX3i
• Configuration:
  8 single-ended or
  4 differential channels
• Resolution: 24-bit precision
• Sampling Rate: 1kS/s per channel
• Common-Mode Rejection: >120dB @ 50/60Hz

Signal Performance

• Voltage Ranges:
  ±10V, 0-10V, ±5V, 0-5V, 1-5V
• Current Ranges:
  0-20mA, 4-20mA, ±20mA
• Accuracy:
  ±0.05% of reading @ 25°C
• Input Impedance:
  100kΩ (voltage), 249Ω (current)

Electrical & Environmental

• Power: 3.3V@450mA + 5V@600mA
• Overvoltage: ±60VDC continuous
• Operating Temp: 0°C to 60°C
• Humidity: 5-95% non-condensing
• Autocalibration: On power-up

Comparison Guide

Installation Guide

• Requires RX3i Universal Backplane
• Differential mode: twisted-pair wiring required
• Terminal blocks:
  IC694TBB132 (recommended for shielding)
• Max wire gauge: 14 AWG

Diagnostics & Features

• Smart Alarms:
  • Open wire detection (<1s)
  • Overrange/underrange alerts
  • Rate-of-change monitoring
• Filter Options: 8Hz to 500Hz (6 selectable)
• Automatic terminal block detection

Package Contents

• IC695ALG608 Input Module
• Configuration guide
• Calibration certificate

Shipping & Warranty

• Delivery: FedEx | UPS | DHL (2-day priority)
• Warranty: 12 months
• Certifications: CE, UL, RoHS, IEC 61131

Frequently Asked

Q: Can I mix signal types?
A: Yes – configure each channel independently for voltage or current.

Q: Minimum CPU firmware?
A: Requires RX3i CPU v3.0+ with Proficy ME v5.0 SP3+

Q: Differential vs single-ended?
A: Differential reduces noise in harsh environments but halves channel count.
