GE Fanuc PACSystems Rx3i IC694ALG442 Analog I/O Module

GE Fanuc IC694ALG442: Hybrid Analog I/O Powerhouse

4-in/2-out module for complex control tasks. Handles voltage/current signals with 12-bit precision and 3ms response. Perfect for integrated process systems.

PRECISION SPECIFICATIONS

• Brand: GE Fanuc/Emerson
• Model: IC694ALG442 (Active Product)
• Input Resolution: 5μA current / 2.5mV voltage
• Output Resolution: 0.5μA current / 0.3125mV voltage
• Update Speed: 3ms (all channels)
• Accuracy: ±0.25% @25°C (inputs) / ±0.1% (outputs)
• Power: 95mA @5VDC + 150mA @24VDC
• Voltage Ranges:
  • Inputs: 0-10V, -10 to +10V, 0-20mA, 4-20mA
  • Outputs: 0-10V, -10 to +10V, 0-20mA, 4-20mA

SYSTEM COMPATIBILITY

• PACSystems RX3i (local/distributed)
• RX7i distributed I/O
• Series 90-30/90-70 PLCs
• Works with GE’s Machine Edition software

PACKAGE INCLUDES

• IC694ALG442 module
• Digital configuration guide

SUPPORT & SHIPPING

• 12-month warranty
• Global delivery: FedEx, UPS, DHL
• Real-time tracking included

KEY QUESTIONS

Q: Can inputs/outputs use different signal types?
A: Yes! Configure each channel independently.

Q: What happens during power failure?
A: Outputs hold last value or downscale – your choice.

Q: Is this suitable for hazardous areas?
A: Only with proper enclosures (IP20 rating).

Q: How fast does it update?
A> All channels refresh every 3ms.
