GE Fanuc PACSystem RX3i Isolated Input Module IC694MDL634

GE Fanuc IC694MDL634 – 24V DC Input Module for RX3i Systems

Core Features

• 8-point digital input module for RX3i PacSystems
• 24V DC operation with positive/negative logic support
• Blue identification band for quick voltage recognition
• Input status LEDs for all 8 channels

Technical Specifications

• Brand: GE Fanuc
• Model: IC694MDL634
• Voltage Range: 0-30V DC (rated 24V DC)
• Current Draw: 7mA per input
• Power Consumption: 45mA @5V bus, 62mA @24V
• On-State Voltage: 11.5-30V DC
• Response Time: 7ms typical (on/off)

Environmental Ratings

• Operating Temp: 0°C to 60°C (32°F to 140°F)
• Storage Temp: -40°C to 85°C
• Humidity: 5-95% non-condensing
• Vibration: 10-57Hz @0.0524mm, 57-500Hz @1.0g
• Shock Resistance: 15G for 11ms

Installation Notes

• Terminal types: 24V OUT / 0V OUT
• Input grouping: 1 group of 8 points
• Wiring: Follow GE Fanuc RX3i guidelines

Certifications

• Meets IEC60068-2-27 shock standards
• Complies with IEC60068-2-6 vibration specs
• JISC0911/JISC0912 compliant

Package & Support

• Single module with documentation
• 12-month warranty
• Global shipping via FedEx, UPS, DHL

FAQ

Q: Can this module handle both sinking/sourcing?
A: Yes, supports positive and negative logic

Q: Minimum on-state current?
A: Requires at least 3.2mA to register input

Q: Condensation tolerance?
A: Operates in 5-95% humidity (non-condensing)

Q: LED indicators?
A: 8 green LEDs show real-time input status
