GE Fanuc PACSystem RX3i Isolated Input Module IC694MDL340

GE Fanuc IC694MDL340: 16-Channel 120V AC Output Module

Product Highlights

Industrial AC output module with 16 channels for PACSystems RX3i. Features 120V AC operation and robust protection systems. Made for reliable automation control.

Detailed Specifications

• Channels: 16 outputs (2 groups of 8)
• Voltage Range: 85-132V AC
• Current Capacity:
  • 0.5A per point
  • 3A per group
• Response Times:
  • Turn-on: 1ms max
  • Turn-off: ½ cycle max
• Isolation Protection:
  • 250V AC continuous
  • 1500V AC for 1 minute
• Power Draw: 315mA @ 5V DC
• Leakage Current: 2mA max (off-state)
• Voltage Drop: 1.5V max
• Fuse Protection: 3A fuses (one per group)
• Operating Temp: 0°C to 60°C

Installation & Setup

• Fits any RX3i I/O slot
• Requires external 120V AC power
• Groups can share power or different phases
• Includes LED status indicators per channel
• Built-in RC snubbers for noise protection

Protection & Safety

• Fuse protected output groups
• Optical isolation between channels
• Transient noise suppression
• High inrush handling (20A)
• Meets JISC0911/IEC60068 standards

Package & Support

• IC694MDL340 output module
• Installation documentation
• 12-month performance warranty
• Global shipping: FedEx, UPS, DHL

Technical Questions

Q: Minimum load current requirement?
A: Requires 50mA minimum per channel

Q: Can I replace fuses myself?
A: Yes – use 3A fuses (GE part# 44A724627-111)

Q: Response time for emergency shutdown?
A: ½ cycle maximum turn-off time

Q: Humidity tolerance during operation?
A: Works at 5-95% non-condensing humidity

Q: Status monitoring capabilities?
A: Individual channel LEDs + group fuse (“F”) indicator
