GE Fanuc PACSystem RX3i AC Isolated Input module IC694MDL732

GE Fanuc IC694MDL732 8-Channel Output Module

Hot-swappable industrial control module for RX3i systems. 8 positive-logic outputs. 12-24V DC operation. Made for easy installation.

Technical Specifications

• Brand: GE Fanuc
• Model: IC694MDL732
• Series: RX3i PacSystem
• Voltage Range: 12-24V DC
• Output Current: 0.5A per point (2A max per common)
• Response Time: ≤2ms on/off
• Isolation: 250V AC continuous / 1500V AC 1-min
• Power Use: 50mA
• Inrush Current: 4.78A per 10ms

Installation Guide

• Hot-swappable in any RX3i backplane slot
• Connect devices between output and negative bus
• User-supplied external power required
• No internal fuses – add external protection
• Ensure frame ground connection

Compatibility

• RX3i Universal Backplane systems
• PacSystems controllers
• 12-24V DC industrial environments
• Requires external power supply

Safety Certifications

• 250V AC continuous isolation rating
• 1500V AC momentary isolation
• Industrial-grade protection
• Meets global automation standards

Package Contents

• IC694MDL732 output module
• Installation documentation
• No fuses or breakers included

Warranty & Shipping

• 12-month manufacturer warranty
• FedEx/UPS/DHL express shipping
• Worldwide delivery options
• Trackable shipments

Common Questions

Q: Can I replace modules without shutdown?
A: Yes – hot-swap enabled for continuous operation

Q: What protection is needed?
A: Add external fusing for each output circuit

Q: How to verify operation?
A: LED indicators show channel status

Q: Minimum voltage supported?
A: 12V DC – do not use below this level
