GE Fanuc PACSystem RX3i AC Isolated Input Module IC694MDL730

GE Fanuc IC694MDL730 8-Channel Output Module

Industrial-grade 8-output module for RX3i systems. 12-24V DC operation with 2A per point capacity. Features dual fuses and status LEDs for reliable control.

Core Specifications

• Brand: GE Fanuc
• Model: IC694MDL730
• Output Channels: 8 points (1 common group)
• Voltage Range: 12-24V DC ±20%
• Current Capacity: 2A per point
• Response Time: <2 ms

Technical Performance

• Isolation: 1500V field-to-logic
• Power Draw: 55 mA total
• Voltage Drop: ≤1.2V
• Inrush Current: 9.4A (10ms)
• Temp Derating: Required above 50°C

Protection & Monitoring

• Fuse Protection: Dual 5-Amp fuses
• Status Indicators: Per-channel LEDs
• Wiring: Common positive bus

Installation Notes

• Max ambient temp: 60°C
• Current derating required at high temps
• Allow heat dissipation space

Industrial Compatibility

• RX3i PacSystems
• Motor starters/contactors
• Indicator lamps
• Solenoid valves
• Relay controls

Safety Certifications

1500V isolation certified. Complies with industrial standards.

Package Contents

• IC694MDL730 module
• Installation guide
• 12-month manufacturer warranty

Shipping Options

• FedEx Industrial
• UPS Critical
• DHL Automation
• Global 2-5 day delivery

Technical Parameters

• Current at 50°C: 4A (derated)
• Current at 60°C: 2A (max rated)
• Bus Connection: Positive sourcing
• Heat Dissipation: 1.5W per point

Frequently Asked

Q: Can all 8 outputs run at 2A simultaneously?
A: Yes, with proper heat management

Q: What happens during power surge?
A: Dual 5A fuses protect entire group

Q: Compatible with AC loads?
A: No – DC only (12-24V)

Q: Status monitoring possible?
A: Yes – per-channel LED indicators

Q: Warranty coverage?
A: 12 months from shipment date
