Bently Nevada Without Armor 3300 XL 8 mm ETR Probe 330191-00-33-90-CN

Bently Nevada 3300 XL 8mm ETR Proximity Probe – Certified for Country-Specific Compliance

Description

The Bently Nevada 330191-00-33-90-CN proximity probe combines rugged design with country-specific certifications. Features TipLoc molding for tip integrity and CableLoc (330N pull strength) for secure connections. Optional FluidLoc blocks oil leaks. Ideal for regulated industries requiring local compliance.

Technical Data

• Brand: Bently Nevada
• Model: 330191-00-33-90-CN
• Voltage: -17.5 Vdc to -26 Vdc (12 mA max)
• Output: 50 Ω resistance, <2 mV/V sensitivity
• Temperature: -55°C to +232°C (T1 rating)
• Cable: 9.0 meters (29.5 ft), FEP/PFA options
• Thread: 3/8-24 UNF, 0.563″ max engagement

Model Suffix Explained

• 330191: 8mm ETR probe base
• 00: No armor
• 33: 3.3″ case length
• 90: 9.0-meter cable
• CN: Country-specific agency approval

Certifications & Compliance

• Approvals: Meets local regulatory standards (marked by “CN” suffix)
• Safety: EPL Ga/Gc/Dc compliant
• Warranty: 12 months, factory-sealed

Installation & Use

Integrates with Bently Nevada extension cables. Max torque: 0.565 N•m. For 1-meter systems, no extension needed. Viton® O-ring ensures pressure sealing.

Global Shipping

Fast delivery via FedEx, UPS, or DHL. Includes installation guide.

Typical Applications

• Power plant turbine monitoring (local compliance)
• Oil & gas pipeline vibration analysis
• Manufacturing equipment diagnostics
