Bently Nevada Metric 3300 NSv Proximity Probe 330905-00-16-05-02-CN

Product Highlights

Bently Nevada 330905-00-16-05-02-CN is a 160mm-case vibration sensor with M10X1 thread. Factory-sealed with 1-year warranty. Direct upgrade to 3300 RAM probes – 22% better chemical resistance.

Part Code Breakdown for 330905-00-16-05-02-CN

• -00: 0mm unthreaded section
• -16: 160mm case length
• -05: 0.5m cable (20″)
• -02: ClickLoc connector
• -CN: China GB standards

Key Specs

• 4.0Ω resistance (±0.5Ω at 0.5m)
• Measures 1.5mm gaps (0.25-1.75mm)
• 7.87V/mm output (±12.5% tolerance)
• Tracks 10kHz vibrations

Installation Guide

• Set 1.0mm gap from target
• Max 7.5N•m torque (first 3 threads)
• Use 24 AWG shielded cable (305m max)

Durability

• Tip: PPS plastic (oil/chemical resistant)
• Case: AISI 304 stainless steel
• Works in -52°C to +177°C

Cable Specs

• Bend radius: 25.4mm minimum
• Shield: 0.066Ω/m resistance
• Capacitance: 69.9pF/m

Important Notes

• For shafts under 13mm, reduce gap by 25%
• Complies with China GB standards
