Product Overview
The Bently Nevada 330905-00-25-05-02-05 is a vibration sensor for factory machines. New & sealed in original box with 1-year warranty. Works in very cold (-52°C) to hot (+177°C) conditions.
Key Features
- Strong Build: 250mm steel case, M10X1 thread, 0.5m cable. Easy-click connector.
- Accurate Reading: Measures 1.5mm range (0.25mm–1.75mm). Output: 7.87V/mm ±20%. Error: ±0.06mm.
- Better Than Old Models: Fits older 3300 RAM probes. Resists chemicals better.
Technical Specs
- Probe Data: 4.2Ω resistance. Max twist force: 0.56 N•m.
- Cables: Use 3-core wire (16-24 AWG). Max length: 305m. Bend radius: 25.4mm.
- For Best Results: Use on shafts ≥13mm. Adjust gap for smaller shafts (see guide).
330905-00-25-05-02-05 Codes
-00 (no threads),
-25 (250mm case),
-05 (0.5m cable),
-02 (connector type),
-05 (certified).
Why Buy This?
- 1-year warranty
- Easy to install
- Reliable in tough jobs
