Product Overview
The Bently Nevada 330905-00-21-05-02-00 is a 3300 NSv Proximity Probe with M10X1 thread (no armor). New & original, includes a 12-month warranty.
Key Specs
- Part Number: 330905-00-21-05-02-00
- Unthreaded Length: 0 mm (-00-)
- Case Length: 210 mm (-21-)
- Cable Length: 0.5 m (20 in) (-05)
- Approvals: Not required (-00)
Key Features
- Industrial-grade: Higher chemical resistance vs. 3300 RAM probes
- Measure Range: 1.5 mm (60 mils) from 0.25–1.75 mm
- Probe Resistance: 4.0 ± 0.5 Ω (0.5 m cable)
- Max Torque: 0.56 N•m (5 in•lb)
Durability & Use
- Temp Range: -52°C to +177°C (-62°F to +351°F)
- Seal: Viton O-ring (pressure tests available on request)
- Field Wiring: Supports up to 305 m (1,000 ft) shielded cable
- Target Size: Min 8.9 mm (0.35″) diameter
