Bently Nevada – 9200-06-05-05-00 Two-Wire Velocity Transducer

Bently Nevada 9200-06-05-05-00 Vibration Transducer

Professional-grade vibration sensor with direct terminal connections for reliable machine monitoring in tough industrial environments.

Main Features

• Terminal block for secure wiring
• 1/2-20 UNF stud for easy mounting
• Wide frequency range (10Hz-1kHz)
• Durable anodized aluminum housing
• 12-month manufacturer warranty

Model Configuration

9200-06-05-05-00

• 9200: Base model
• 06: 0±100° mount, 10Hz minimum
• 05: Terminal block connection
• 05: 1/2-20 UNF stud mount
• 00: No agency approvals

Technical Specifications

• Velocity range: 0-25 mm/s
• Sensitivity: 20mV/mm/s (±5%)
• Temperature range: -29°C to +121°C
• Coil resistance: 1.25kΩ ±5%
• Weight: 300g (10.5oz)
• IP rating: Dust/moisture resistant

Package Contents

• 9200-06-05-05-00 transducer
• Mounting hardware
• Neoprene gasket

Expert Questions Answered

Q: What’s the advantage of terminal block connection?
A: Allows secure, vibration-resistant wiring without special connectors.

Q: What tools are needed for installation?
A: Standard 1/2-20 UNF wrench for mounting.

Q: How sensitive is it to mounting angle?
A: Works at 0° ±100° for flexible installation.

Q: Can it measure high-speed equipment?
A: Yes, measures vibrations up to 1kHz (60,000 RPM).

Q: Is calibration required?
A: No, pre-calibrated at factory for immediate use.

Download Resources

• Installation Manual (PDF)
• Full Specifications Sheet
• Application Guide
