Bently Nevada 33300 XL 11 mm Proximity Probe 330707-00-24-90-11-00

Bently Nevada 330707-00-24-90-11-00 – Premium 11mm Vibration Probe

Key Features

• ✔ 9-meter long armored cable (29.5 feet)
• ✔ 5/8-18 UNF thread for secure mounting
• ✔ Works in extreme temperatures (-52°C to +177°C)
• ✔ Stainless steel case with PPS tip
• ✔ ClickLoc connector with protector

Complete Model Number Breakdown

 330707 → 3300 XL 11mm Probe (5/8-18 UNF) -00 → 0" unthreaded length -24 → 2.4" case length -90 → 9.0m cable length -11 → ClickLoc connector with protector -00 → No agency approvals needed

Technical Specifications

• Cable Type: 75Ω triaxial FEP insulated
• Resistance: 8.5 ± 1.1 ohms (9m length)
• Thread Torque: Max 45.2 N•m (400 in•lb)
• Recommended Torque: 15.2 N•m (133 in•lb)
• Bend Radius: Minimum 25.4mm (1.0 in)
• Weight: 0.17 kg
• Connector Torque: Finger tight (max 0.565 N•m)

Warranty & Shipping

• 12-month quality guarantee
• Fast worldwide shipping via FedEx, UPS, or DHL

Expert FAQs

• Q: Can I use this with shorter cables?
  A: No, this model is fixed at 9 meters
• Q: Is the connector waterproof?
  A: The FluidLoc cable provides fluid resistance
• Q: What’s the thread engagement length?
  A: Maximum 0.938 inches
• Q: Can it handle high pressure?
  A: Has Viton O-ring but not pressure-tested
• Q: What’s the cable insulation?
  A: Fluoroethylene propylene (FEP)
