Bently Nevada – 330881-28-00-135-03-00 – PROXPAC XL Proximity Transducer

🚀 Essential Specs: Bently Nevada

330881-28-00-135-03-00 Industrial-grade PROXPAC XL transducer with 135mm probe penetration. 1-year warranty. Made in USA.

🔧 Configuration Highlights for 330881-28-00-135-03-00

• Probe: 8mm 3300 XL (Multi-certified)
• Penetration: 135mm (C dimension)
• Fittings: 1×M20 + 2 plugs
• Weight: 1.44kg / 3.2lbs
• Mounting: No outer sleeve required

⚡ Performance Features

• Voltage Range: -17.5V to -26V DC
• Temp Tolerance: -51°C to +177°C
• Accuracy: ±0.025mm (±1 mil)
• Min Target Size: 15.2mm diameter

🛡️ Rugged Build

• Housing: IP66 certified (BASEEFA T07/0709)
• Probe Material: PPS tip + AISI 304 steel
• Cable: 1m triaxial (75Ω FEP shielded)
• Impact Rated: 4J@-39°C & 7J@room temp

🔩 Installation Kit

• Included: M20 fitting + 2 plugs
• Torque Specs:
  – Retaining Nut: 29.5N·m
  – Locknut: 39.3N·m
• Wiring: Up to 305m (16-24 AWG)

📜 Certifications

• BASEEFA & CSA certified
• COO available
• 12-month coverage

Document Download Here:PROXPAC XL Proximity Transducer Assembly Datasheet
