Bently Nevada | 330709-000-060-90-02-00 – 3300 XL 11 mm Proximity Probe

Bently Nevada 330709-000-060-90-02-00 3300 XL 11mm Proximity Probe

Model Details

• Base model: 330709
• Unthreaded length: 0mm
• Case length: 60mm
• Cable length: 9.0m (29.5 feet)
• Connector: Miniature coaxial ClickLoc with standard cable
• Certifications: None required

Main Features

• Resistance: 8.5 ±1.1 ohms (for 9.0m length)
• Min target size: 30.5mm (flat surface) / 152mm (shaft)
• Tip material: PPS plastic
• Case material: 304 stainless steel
• Cable: 75Ω triaxial, FEP insulated (1m/5m/9m options)
• Working temp: -52°C to +177°C

Installation Tips

• Thread size: M16x1.5
• Max thread fit: 24mm
• Case tightening: 63.3N·m
• Connector tightening: Hand-tight (max 0.565N·m)
• Min bend radius: 25.4mm (1in)

Important Notes

Avoid using below -34°C to prevent pressure seal damage. Designed for extended-range industrial monitoring systems.

Package & Delivery

• Includes: Probe, 9.0m cable, O-ring, user manual
• Shipping: Fedex/UPS/DHL (5-8 days)
