Bently Nevada 330708-00-24-10-11-00 – 3300 XL 11mm Industrial Probe with FluidLoc Protection
Oil-resistant vibration sensor with connector armor and compact 2.4″ design. Made in USA. 12-month warranty. Ships fast via FedEx/UPS/DHL.
Built for Tough Environments
- 🛡️ FluidLoc cable – resists oils and chemicals
- 🔒 Connector protector – prevents damage in harsh conditions
- 📏 2.4″ compact body – fits tight spaces
- ❄️ -51°C to +177°C operating range
- ⚖️ 5.9Ω resistance (1m cable version)
Model Number Breakdown
330708-00-24-10-11-00
├─ 330708 → 11mm probe base
├─ 00 → No unthreaded section
├─ 24 → 2.4″ case length
├─ 10 → 1.0m cable
├─ 11 → ClickLoc+FluidLoc
└─ 00 → No approvals needed
├─ 330708 → 11mm probe base
├─ 00 → No unthreaded section
├─ 24 → 2.4″ case length
├─ 10 → 1.0m cable
├─ 11 → ClickLoc+FluidLoc
└─ 00 → No approvals needed
Technical Highlights
- Thread: Standard 5/8-18 UNF
- Max Torque: 400 in-lb (recommend 133 in-lb)
- Cable Type: 75Ω triaxial FEP
- Min Bend Radius: 1.0 inch
- Weight: Just 0.37 lbs (0.17 kg)
- Seal Material: Viton O-ring (avoid below -34°C)
Expert Questions Answered
- Q: How does FluidLoc differ from standard cable?
A: Special jacketing resists oils, chemicals, and moisture - Q: Why use the connector protector?
A: Prevents damage in high-vibration or impact areas - Q: Can I submerge this probe?
A: Not fully submersible – moisture-resistant only - Q: What’s the advantage of 2.4″ housing?
A: 40% shorter than standard 4″ models - Q: Is the protector removable?
A: Yes, but not recommended for normal operation
