Bently Nevada 330701-00-10-10-01-05 3300 XL 11 mm Proximity Probe

Bently Nevada 3300 XL 11mm Proximity Probe – Compact Certified Version

Quick Facts

• ⭐ Model: 3300 XL 11mm (330701-00-10-10-01-05)
• ⭐ Size: Ultra-compact 1.0″ case
• ⭐ Cable: 1.0m (3.3ft) with connector protector
• ⭐ Certified: Multiple international approvals
• ⭐ Protection: 12-month quality guarantee

Model Number Decoder

330701
├─ 00 → 0" unthreaded
├─ 10 → 1.0" case
├─ 10 → 1.0m cable
├─ 01 → ClickLoc+protector
└─ 05 → Multi-certified

Technical Specifications

• 🔧 Resistance: 5.9 ± 0.5Ω (1m)
• 🔧 Thread: 1/2-20 UNF & M16x1.5
• 🔧 Install Torque: 15.2 N•m (133 in-lb)
• 🔧 Connector Torque: Finger tight (max 0.565 N•m)
• 🔧 Bend Radius: Min 25.4mm (1.0″)
• 🔧 Weight: Lightweight 0.17kg
• 🔧 Temp Range: -51°C to +177°C

Professional FAQs

• 💡 What certifications does “05” include?
  Covers multiple international standards (ask for details)
• 💡 Why choose 1.0″ case?
  Fits tight spaces where standard probes won’t
• 💡 What’s the connector protector?
  Extra shield for connection points
• 💡 Minimum install temperature?
  Don’t install below -34°C to protect seals
• 💡 Pressure rating?
  Not tested by default (available on request)

Order Information

• 🚀 Fast shipping: FedEx/UPS/DHL
• 🛡️ 12-month warranty coverage
• 🏭 Made in USA
