Bently Nevada 330500 – Velomitor Piezo – 330500-00-02 | velocity Sensor

Bently Nevada 330500 Velomitor Piezo-Velocity Sensor

Description

Bently Nevada 330500-00-02 is an industrial-grade piezo-velocity sensor with ATEX certification for hazardous environments. Built with 316L stainless steel, it ensures durability in extreme conditions. Features hermetic sealing and supports cable lengths up to 305 meters without signal loss.

Technical Data

• Brand: Bently Nevada
• Model: 330500-00–02
  • -00: No adapter mounting thread
  • -02: ATEX (EU) hazardous area approval
• Range: 1270 mm/s peak | Accuracy: ±5% sensitivity
• Output: 3.94mV/mm/s | Noise: 0.004 mm/s rms
• Temp Range: -55°C to 121°C | Resonance: >12 kHz

Installation Guide

• Apply 24-40 in-lb torque for secure mounting
• Max cable: 305m (part# 02173006)
• Polarity: Case motion toward connector makes Pin A positive

Certificated

• FCC Part 15 | EMC 2014/30/EU | RoHS 2011/65/EU
• ATEX Ex ia/IIC T4 | DNV maritime standards
