Bently Nevada – 330106-05-30-90-02-00 | 3300 XL 8mm Proximity Probe

Bently Nevada 330106-05-30-90-02-00 3300 XL 8 mm Reverse Mount Probe

Technical Specifications

• Model: 330106-05-30-90-02-00
• Thread Type: M10 x 1
• Total Length: 9.0 meters (29.5 feet)
• Connector Type: Miniature ClickLoc coaxial
• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 303 or 304 stainless steel
• Resistance: 9.87 ± 0.50 ohms at 9 m length
• Cable Type: 75Ω triaxial, FEP or PFA insulated
• Operating Temp (Standard): -52°C to +177°C
• Operating Temp (Extended): -52°C to +218°C (tip)
• Max Pressure Seal: Sealed with Viton O-ring
• Weight: 323 g/m (11.4 oz)
• Humidity Resistance: <3% ASF change in 93% RH

Mounting Guide

• Use M10 x 1 threaded ports with max thread depth of 15 mm
• Maintain clean, dry installation surface
• Use proper torque to secure the probe for reliable sealing

Shipping Options

• FedEx
• UPS
• DHL

Full Model Tree

• Base Model: 330106 = 3300 XL 8 mm Reverse Mount Probe
• Suffix 05: Cable Length Code = 9 meters
• Suffix 30: Target Material = Standard steel
• Suffix 90: Total Probe Length = 9.0 meters
• Suffix 02: Connector = Miniature ClickLoc coaxial
• Suffix 00: No agency approval required
