Bently Nevada | 3300 XL 8mm Reverse Mount Probe 330105-02-12-50-12-00

🔍 Precision Engineered Probe System

Bently Nevada 330105-02-12-50-12-00 reverse-mount probe delivers industrial reliability with 5.0m FluidLoc cable (-12). Made in USA. Non-certified version (-00) for general applications. COO available.

⚙️ Core Specifications for 330105-02-12-50-12-00

• ▸ DC Resistance: 8.73Ω ±0.50Ω @5m
• ▸ Dimensions: 20.4×22.2×3.7cm
• ▸ Weight: 323g/m (11.4oz/ft)
• ▸ Thread: 3/8-24 (14.3mm max grip)

🌡️ Thermal Performance Profile

• Standard Range: -52°C to +177°C
• Extended Capacity:
• • Probe Tip: +218°C peak
• • Cable Endurance: +260°C maximum
• ⚠️ Critical Note: Avoid below -34°C to protect seals

⚠️ FluidLoc Advisory

• The -12 suffix indicates FluidLoc cable – required only for:
• • Non-sleeve installations
• • Special fluid environments
• Most applications use standard probe sleeves instead.

🔠 Suffix Decryption

• ▷ -02-12: 8mm probe + connector type
• ▷ -50: 5.0 meter cable length
• ▷ -12: FluidLoc cable option
• ▷ -00: No agency certifications

🛠️ Complete Configuration

Includes:
• Viton® O-ring pressure seal
• 1-year defect warranty
• Ships untested per industry standard

Document Download Here: 3300 XL 8 mm Proximity Transducer System Datasheet
