Bently Nevada 3300 XL 8mm Long-Body Proximity Probe
Key Features
- Extended reach: 130mm stainless steel case
- Deep installation: Ideal for hard-to-access machinery
- Precision sensing: 2mm linear range (0.25-2.3mm gap)
- Rugged construction: PPS tip + Viton® seal
Technical Specifications
| Full Model | 330103-00-13-10-02-00 |
| Suffix Details |
|
| Electrical | 7.59Ω ±0.50Ω resistance |
| Weight | 323 g/m (11.4 oz/ft) |
Installation Guide
- Mounting depth: Max 15mm thread engagement
- Cable management: Use strain relief near connector
- Avoid cold exposure: Below -34°C risks seal damage
Compatibility
- 3300 XL Proximitor monitoring systems
- Requires zener barriers for hazardous areas
- Works with standard triad shielded cable
Package & Warranty
- 1x 130mm probe with 1.0m cable
- ClickLoc connector pre-installed
- 12-month warranty
- Express shipping: FedEx/UPS/DHL
FAQ
Q: Can this probe monitor thrust position?
A: Yes, when axially mounted with proper calibration.
Q: Is the cable replaceable if damaged?
A: No, cable is permanently attached to probe.
Q: Suitable for food processing equipment?
A: Yes, SST and PPS materials meet sanitary requirements.
