3300 NSv Reverse Mount Probe (0.5M Multi-Cert)
Bently Nevada | PN: 330907-05-30-05-02-05 | 1-Year Warranty
Compact industrial probe with 4.0Ω DC resistance. Features standard cable and 5 global certifications. Operates at -52°C to +177°C. Free COO available.
Core Specifications
- Thread: M10X1 Reverse Mount
- Cable: 0.5M (20″) Standard
- Connector: ClickLoc Coaxial (02 Type)
- Certifications: 05 (Multi-Approved)
Technical Performance
| Measurement | 0.25-1.75mm Range | Max Torque | 7.5 N•m |
| Wire Gauge | 16-24 AWG | Response Graphs | Fig16-17 |
| Seal Type | Viton O-Ring | Thread Fit | 15mm |
Critical Alerts
- ⚠️ Temperatures below -34°C damage seals
- ⚠️ Keep cables under 305m for signal quality
- ⚠️ Required gap: 1.0mm ±0.05mm
Order Code Details
330907-05-30-05-02-05 =
M10X1 Threads (05-30) | 0.5M Length (05) | Standard Cable (02) | Multi-Cert (05)
