Allen-Bradley ControlLogix | 1756-OF6VI Voltage Output Module

Allen-Bradley 1756-OF6VI – High-Performance 6-Channel Isolated Voltage Output Module

Key Advantages

• 🔋 6 fully isolated voltage outputs
• 🔋 ±10VDC range with 14-bit precision
• 🔋 Ultra-fast <2ms settling time
• 🔋 1000Ω+ load drive capability
• 🔋 Built for harsh industrial environments

Technical Specifications

• Model: 1756-OF6VI (ControlLogix Series)
• Output Type: Isolated voltage only
• Voltage Range: ±10.5VDC
• Resolution: 14-bit (1.3mV steps)
• Accuracy: ±0.5% of range
• Power Use: 250mA @ 5.1V DC, 175mA @ 24V DC
• Temp Stability: 60μV/°C typical drift
• Response Time: 10ms (integer), 25ms (float)

Durability Features

• 🛡️ Withstands 30G shocks
• 🛡️ 2G vibration resistance
• 🛡️ Operates in 5-95% humidity

Your Protection

• 🔒 12-month performance guarantee
• ✈ Fast global shipping options
• 🔄 6-month calibration cycle

Expert Questions

• Q: What’s the minimum load requirement?
  A: 10mA minimum current draw.
• Q: Does it support current outputs?
  A: No, voltage output only (±10VDC).
• Q: How stable is the output?
  A: Typical drift of 60μV/°C.
• Q: What’s the isolation rating?
  A: 250V continuous isolation.
• Q: Can it drive long cable runs?
  A: Yes, supports >1000Ω loads.

Resources

• 📥 Download 1756-OF6VI full specifications
