Allen-Bradley 1769-L24ER-QBFC1B CompactLogix Controller – Complete Machine Control Solution
- All-in-one controller with built-in I/O and motion capabilities
- Perfect for packaging, material handling and small automation projects
- Download complete specifications
Key Features
- Built-in I/O: 16DI/16DO/4AI/2AO/4HSC
- Dual Ethernet ports with Device Level Ring (DLR) support
- 1MB memory + 1GB SD card (expandable to 2GB)
- Supports 2 motion axes over Ethernet/IP
- Compact DIN rail mounting (only 2″ wide)
Technical Specifications
| Model | 1769-L24ER-QBFC1B (5370 L2 Series) |
| Digital I/O | 16 inputs (sink/source) + 16 outputs (sinking) |
| Analog I/O | 4 inputs + 2 outputs |
| High-Speed I/O | 4 counters + 4 outputs |
| Communication | 2x EtherNet/IP, 1x RS-232, 1x USB |
| Power | 24V DC (1A @5V, 0.8A @24V) |
| Dimensions | 11 x 8 x 6 in (279 x 203 x 152 mm) |
| Weight | 3 lbs (1.36 kg) |
Expert FAQs
- Q: What motion control is supported?
A: Controls 2 axes over Ethernet/IP. - Q: Can I expand the I/O?
A: Yes, supports 4 additional 1769 modules. - Q: What thermocouples work?
A: Supports Types K, J, T, E, N, B, S, R. - Q: Programming software needed?
A: Requires Studio 5000 Logix Designer. - Q: Shipping time?
A: 2-3 business days via FedEx/UPS/DHL.
Warranty & Support
Backed by 12-month protection. Free technical support available.
