Allen-Bradley 1769-OB8 – Powerful 8-Channel
- Reliable control for 8 DC devices in one compact module
- High-current outputs handle demanding industrial loads
- Easy integration with CompactLogix and MicroLogix systems
- Flexible mounting on DIN rail or panel
- Complete specs: Download Technical Manual
Key Features
The 1769-OB8 delivers 8 protected DC outputs with 24V DC operation. Perfect for controlling relays, solenoids, and indicators in automation systems.
Technical Specifications
- Brand: Allen-Bradley
- Model: 1769-OB8 (Series A/B)
- Outputs: 8 channels (2 groups of 4)
- Voltage: 20.4-26.4V DC
- Current: 0.5A continuous per point
- Surge Capacity: 4A for 10ms (repeatable)
- Power Draw: 145mA @5.1V DC
- Wire Size: 22-16 AWG stranded
- Dimensions: 8 x 8 x 5 inches
- Weight: 2 lbs
- Response Time: <1ms switching
Installation Guide
Simple DIN rail or panel mount installation. Use with 1769-RTBN18 terminal block for easy wiring.
Our Guarantee
- 12-month product warranty
- Fast worldwide shipping via FedEx, UPS, DHL
Expert Answers
- Can I mix different load types? Yes – works with relays, solenoids, and indicators.
- What’s the minimum load current? 1mA minimum required for proper operation.
- Is this module fused? No – but has electronic protection against overloads.
- Can I use it with 12V devices? No – requires minimum 20.4V DC.
- How many modules per system? Up to 8 modules from power supply.
