Allen-Bradley 22D-E3P0N104 PowerFlex 40P AC Drive

Allen-Bradley 22D-E3P0N104 PowerFlex Drive – 2HP Motor Control

Drive Features

• 2HP power for industrial applications
• Works with 600V 3-phase power
• Easy panel mounting (IP20 rated)
• Dual control options (V/Hz & Sensorless)
• Advanced voltage protection system

Technical Specifications

• Model: 22D-E3P0N104
• Input: 414-660V AC, 3.8A, 3-phase
• Output: 3A, 1.5kW (2HP)
• Voltage Range: 0-575V AC output
• Display: 4-digit LED with 10 status lights
• Size: 3.9″ × 9.6″ × 6.3″ (100×244×161mm)
• Weight: 5.5 lbs (2.5 kg)
• Protection: Overvoltage (1005V DC) and Undervoltage (390V/487V DC)
• Mounting: Panel (vertical)

Package Contents

• 22D-E3P0N104 drive unit
• Mounting hardware
• Quick start guide

Warranty & Support

• 12-month product warranty
• Free technical support
• 30-day return policy

Shipping Options

• FedEx Ground (3-5 days)
• UPS 2-Day Air
• DHL Express International

Expert Questions

• Q: What’s the minimum input voltage?
  A: 414V AC (3-phase)
• Q: Can I mount this horizontally?
  A: No, vertical mounting only
• Q: What wire size should I use?
  A: Minimum 14 AWG recommended
• Q: Does it include a cooling fan?
  A: Yes, with thermal protection
• Q: Can I network multiple drives?
  A: Yes, via optional communication cards
