Allen-Bradley | 2094-BC04-M03-M Kinetix 6000 Axis Module

Allen-Bradley 2094-BC04-M03-M Servo Drive – 27.6kW High Power

Powerful Performance

• 27.6kW continuous power output
• Massive 41.5A continuous current
• Peak current: 75.0A (0-pk)
• Works with 360-480V AC 3-phase
• 98% energy efficient operation

Technical Specifications

• Model: 2094-BC04-M03-M
• Input voltage: 324-528V AC (3-phase)
• DC bus voltage: 458-747V DC
• Peak power: 69.0kW
• Short-circuit rating: 200,000A
• Efficiency: 98%
• Weight: 21 lbs (9.53kg)
• Dimensions: 11.9×16.7×7.7 in
• PWM frequency: 4kHz

Protection & Safety

• Bus overvoltage: 825V DC
• Bus undervoltage: 275V DC
• Recommended fuses: FNQ-R-10/FNQ-R-7.5
• Circuit breakers: 1492-SPM2D060/1492-SPM1D150
• CE certified

Installation Guide

• Clearance: 50.8mm (2″) minimum
• Enclosure depth: ≥272mm (10.7″)
• Control voltage: 95-264V AC (1-phase)
• Mounts on Kinetix power rail

Our Warranty

• 12-month full protection
• Covers all manufacturing defects
• Priority replacement service

Shipping Options

• FedEx Priority Overnight
• UPS 2-Day Air
• DHL Express Worldwide

Expert Questions

• Q: What’s the difference between M03 and M01 models?
  A: M03 offers higher power (27.6kW vs 6kW).
• Q: Can this drive handle voltage spikes?
  A: Yes, protects up to 825V DC spikes.
• Q: What cooling is required?
  A: Designed for natural convection at full load.
• Q: How many motors can it control?
  A: Controls one servo motor per module.
• Q: What’s the response time?
  A> Current loop bandwidth of 1300Hz.
