Allen-Bradley 1769-OF4VI: Premium 4-Channel Isolated Voltage Output
Precision Control Solution
The Allen-Bradley 1769-OF4VI delivers industrial-grade voltage control. This 4-channel isolated module provides ultra-precise 0-10V signals with 15-bit resolution. Perfect for sensitive equipment requiring electrical isolation between outputs.
Key Specifications
| Brand/Model | Allen-Bradley 1769-OF4VI Series A/B |
| Output Type | 4 isolated voltage channels |
| Voltage Range | 0-10V (±0.5% accuracy) |
| Resolution | 15-bit (330 μV/bit) |
| Response Time | 0.4ms power-up / 21ms power-down |
| Load Capacity | ≤2kΩ resistive / 1μF capacitive |
| Protection | Short-circuit proof (42mA max) |
| Power Consumption | 165mA @ 5VDC (2W dissipation) |
Easy Integration
DIN rail mounting. Position within 8 modules of power source. Works from 0°C to 60°C (32°F to 140°F).
System Compatibility
Designed for CompactLogix control systems. Earth ground supported.
Safety Certified
Features IEC Class 2 reinforced insulation for maximum protection.
Your Assurance
12-month performance guarantee included.
Shipping Options
FedEx, UPS, or DHL. Package size: 8″x8″x5″ (2 lbs weight).
Expert Resources
- Download full technical specifications
- Access wiring diagrams
- Get installation tips
- Download 1769-OF4VI Manual Now
Technical FAQs
Q1: What isolation does the 1769-OF4VI provide?
A: Each channel has full electrical isolation for safety.
Q2: Can I replace terminal blocks?
A: Yes – replacement terminal blocks are available.
Q3: What’s the resolution accuracy?
A: ±0.5% full scale at normal temperatures.
Q4: How fast does it respond to signals?
A: Powers up in under 0.4 milliseconds.
Q5: Is calibration required?
A: No – maintains precision without field calibration.
