Allen-Bradley 1769-L27ERM-QBFC1B CompactLogix Controller – High-Performance Motion PAC
- Advanced control with 16-axis motion over EtherNet/IP
- Complete built-in I/O (16DI/16DO/4AI/2AO/4HSC) for machine automation
- Download full technical manual
Key Benefits
- 1MB memory + 1GB SD card (upgradable to 2GB)
- Dual EtherNet/IP ports with DLR support
- Supports 4 expansion modules + 1 I/O bank
- Wide analog input support (RTD, thermocouple, voltage/current)
- Compact design saves 40% panel space
Technical Specifications
| Model | 1769-L27ERM-QBFC1B (5370 L2 Series) |
| Motion Control | 16 axes over EtherNet/IP |
| Built-in I/O | 16DI/16DO/4AI/2AO/4HSC |
| Analog Inputs | Supports 9 thermocouple types + RTD |
| Communication | 2x EtherNet/IP, 1x USB |
| Power | 24V DC (3A max) |
| Dimensions | 11 x 8 x 6 in (279 x 203 x 152 mm) |
| Weight | 3 lbs (1.36 kg) |
Expert FAQs
- Q: What motion drives are compatible?
A: Works with Kinetix 350/5500/5700/6500 series. - Q: Can I use both Ethernet ports?
A: Yes, for network redundancy or separate networks. - Q: What’s the analog resolution?
A: 16-bit for unipolar, 15-bit+sign for bipolar. - Q: Programming software required?
A: Studio 5000 Logix Designer (v24+ recommended). - Q: Shipping options?
A: Next-day air available via FedEx/UPS/DHL.
Warranty & Support
Includes 12-month coverage. Free lifetime technical support.
