Allen-Bradley 1769-L23E-QBFC1B CompactLogix Controller – All-in-One Machine Control
- Ready-to-run solution with built-in I/O (16DI/16DO/4AI/2AO)
- Includes 4 high-speed counters for motion applications
- Download product manual
Key Features
- Integrated I/O: 16DI, 16DO, 4AI, 2AO, 4HSC
- Dual communication: EtherNet/IP + RS-232 (DF1/ASCII)
- Compact design: Only 1.97″ (50mm) width
- Supports 2 expansion modules (1769 series)
- 512KB user memory with battery backup (1769-BA)
Technical Specifications
| Model | 1769-L23E-QBFC1B (5370 L2 Series) |
| Built-in I/O | 16DI/16DO/4AI/2AO/4HSC |
| Network Speed | 10/100 Mbps Ethernet |
| Serial Port | RS-232 (38.4Kbps max) |
| Power | 24V DC operation |
| Expansion | 2x 1769 I/O modules |
| Dimensions | 1.97 x 5.91 x 3.94 in (50 x 150 x 100 mm) |
Professional FAQs
- Q: Can I add DeviceNet?
A: Yes, with 1769-SDN scanner module. - Q: What cables are needed?
A: 1756-CP3 for RS-232, Cat5e for Ethernet. - Q: Is the battery replaceable?
A: Yes, uses standard 1769-BA battery. - Q: Programming software?
A: Studio 5000 Logix Designer required. - Q: Shipping options?
A: Next-day via FedEx/UPS/DHL available.
Warranty & Support
Includes 12-month coverage. Our control experts provide free technical support.
