Bently Nevada 330910-05-09-50-01-CN | 3300 NSv Proximity Probe

Model Configuration Breakdown

• Model Base: 330905 – 3300 NSv Probe, M10X1 thread, armored
• Unthreaded Length: 05 = 50 mm (must be at least 20 mm less than case)
• Case Length: 09 = 90 mm
• Total Probe Length: 50 = 5.0 meters (16.4 feet)
• Connector Option: 01 = ClickLoc miniature coaxial with connector protector
• Agency Approval: CN = Country-specific compliance

Technical Specifications

• Output Type: Passive signal with resistance output
• Resistance (5.0 m cable): 5.3 ± 0.7 ohms
• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 304 stainless steel
• Cable Type: 75 Ω coaxial, FEP insulated
• Cable Length Options: 0.5 m, 1 m, 5 m, 7 m
• Operating Temperature: -52°C to +177°C
• Storage Temperature: -52°C to +177°C
• Weight: 14–150 g

Mechanical Torque Ratings

• Max Probe Case Torque: 33.9 N·m (300 in·lb)
• Recommended Torque: 11.3 N·m (100 in·lb)
• Connector Max Torque: 0.56 N·m (5 in·lb)
• Connector Torque Suggestion: Finger tight

Mounting and Installation

• Thread Type: M10x1
• Max Thread Engagement: 15 mm
• Minimum Bend Radius: 25.4 mm
• Use suitable tool to avoid overtightening
• Do not expose probe to below -34°C to maintain seal

Temperature Classifications

• T1: -55°C to +232°C
• T2: -55°C to +177°C
• T3: -55°C to +120°C
• T4: -55°C to +80°C
• T5: -55°C to +40°C
• Dc Rating: Up to 280°C depending on conditions

Package Includes

• 1 x Bently Nevada 330910-05-09-50-01-CN Probe
• 5-meter coaxial cable with ClickLoc connector and protector
• Factory-sealed packaging
• 12-month limited warranty
