Bently Nevada 330910-00-06-70-02-00 Proximity Probe

Overview

The Bently Nevada 330910-00-06-70-02-00 is part of the 3300 NSv series. It features a 60 mm case length and 7.0-meter cable. Designed for tight spaces and small machines.

Key Technical Parameters

• Thread Type: M10x1, with stainless steel armor
• Unthreaded Length: 0 mm
• Case Length: 60 mm
• Cable Length: 7.0 meters (23.0 ft)
• Connector: Miniature ClickLoc
• Cable Type: Standard FEP 75 Ω coaxial
• Tip Material: PPS (Polyphenylene sulfide)
• Case Material: AISI 304 stainless steel
• DC Resistance: 5.9 ± 0.9 Ω

Temperature Specifications

• Operating Range: -52°C to +177°C
• Storage Range: -52°C to +177°C
• Avoid use below -34°C for long periods

Temperature Ratings

• For EPL Ga/Gc
  • T1: -55°C to +232°C
  • T2: -55°C to +177°C
  • T3: -55°C to +120°C
  • T4: -55°C to +80°C
  • T5: -55°C to +40°C
• For EPL Dc
  • T280°C @ Ta -55°C to +232°C
  • T225°C @ Ta -55°C to +177°C
  • T170°C @ Ta -55°C to +120°C
  • T130°C @ Ta -55°C to +80°C
  • T105°C @ Ta -55°C to +100°C
  • T90°C @ Ta -55°C to +40°C

Full Model Breakdown

• 330910 – 3300 NSv Series
• 00 – Unthreaded length: 0 mm
• 06 – Case length: 60 mm
• 70 – Cable length: 7.0 meters
• 02 – ClickLoc connector, standard cable
• 00 – No agency approval

System Compatibility

• 3300 NSv monitoring systems
• Compatible with 3300 extension cables

Warranty and Shipping

• 12-month warranty from factory
• Fast delivery via FedEx, UPS, or DHL
