330905-00-25-05-02-CN | Bently Nevada Metric 3300 NSv Proximity Probe

Product Overview

The Bently Nevada 330905-00-25-05-02-CN is a 3300 NSv Proximity Probe with M10X1 thread. It measures machine vibration and position. New & original, with a 1-year warranty. Works with older 3300 RAM probes but has 22% better chemical resistance.

Key Features for 330905-00-25-05-02-CN

• Suffix Codes: -00 (0mm unthreaded), -25 (250mm case), -05 (0.5m cable), -02 (ClickLoc connector), -CN (China approvals).
• Resistance: 4.0Ω ±0.5Ω (0.5m cable).
• Range: Measures 1.5mm (60 mils) with 7.87V/mm sensitivity (±12.5% tolerance).
• Frequency: Works up to 10kHz with 305m cables.

Technical Specs

• Cable Data: Shield: 0.066Ω/m, capacitance: 69.9pF/m.
• Temperature: Works from -52°C to +177°C (-62°F to +351°F).
• Pressure Seal: Uses Viton O-ring (not tested before shipping).
• Torque: Max 7.5N•m for first 3 threads; 11.3N•m for full case.

Installation Tips

• Gap: Set to 1.0mm (40 mils) from target.
• Target Size: Min 8.9mm, better at 13mm.
• Wiring: Use 24 AWG shielded cable (up to 305m).

Material & Build

• Tip: PPS plastic resists chemicals.
• Case: Stainless steel (AISI 304), bends up to 25.4mm.

Document Download Here:3300 XL NSv Proximity Transducer System Datasheet
