330905-00-10-10-02-00 | Bently Nevada Metric 3300 NSv Proximity Probe

Product Overview

The Bently Nevada 330905-00-10-10-02-00 is a 3300 NSv Proximity Probe with M10X1 thread (no armor). New & original, includes a 12-month warranty.

Key Specs

• Part Number: 330905-00-10-10-02-00
• Unthreaded Length: 0 mm (-00-)
• Case Length: 100 mm (-10-)
• Cable Length: 1.0 m (39 in) (-10)
• Approvals: Not required (-00)

Key Features

• Superior Design: Higher chemical resistance vs. 3300 RAM probes
• Measurement Range: 1.5 mm (60 mils) from 0.25–1.75 mm
• Probe Resistance: 4.2 ± 0.5 Ω (1.0 m cable)
• Max Torque: 0.56 N•m (5 in•lb)

Durability & Performance

• Temp Range: -52°C to +177°C (-62°F to +351°F)
• Seal: Viton O-ring (pressure tests available on request)
• Field Wiring: Up to 305 m (1,000 ft) shielded cable
• Target Size: Min 8.9 mm (0.35″) diameter

Support

Includes 1-year warranty.

Document Download Here: 3300 XL NSv Proximity Transducer System Datasheet
