330901-11-25-10-02-CN 3300 NSv Proximity Probes | Without Armor

Bently Nevada 330901-11-25-10-02-CN Proximity Probe

Product Overview

The 330901-11-25-10-02-CN is a compact proximity probe from Bently Nevada’s 3300 NSv series. It uses a 1/4-28 UNF thread and features a 1.1-inch unthreaded length and 2.5-inch case length. It includes a 1.0-meter cable with a standard ClickLoc connector.

Model Structure

• 330901: 3300 NSv series probe
• 11: 1.1 inch unthreaded length
• 25: 2.5 inch overall case length
• 10: 1.0 meter total probe length
• 02: Miniature coaxial ClickLoc connector, standard cable
• CN: Country-specific approval

Key Technical Specifications

• Output Signal: Non-contact displacement signal
• Resistance: 4.2 ± 0.5 ohms (at 1.0 m)
• Cable Type: 75 Ω coaxial, FEP insulation
• Operating Temperature: -52°C to +177°C
• Storage Temperature: -52°C to +177°C
• Weight: Approx. 0.5 kg

Material Composition

• Probe Case: AISI304 stainless steel
• Probe Tip: Polyphenylene sulfide (PPS)

Installation Guide

• Thread Type: 1/4-28 UNF
• Max Thread Depth: 0.375 inch
• Recommended Torque: 5.1 N·m (45 in·lb)
• Max Torque: 7.3 N·m (65 in·lb)
