Bently Nevada 3300 XL 25mm Proximitor Sensor
Description
The 3300 XL 25mm Proximitor Sensor (330850-50-05)offers advanced monitoring for industrial machinery. Its slim design fits high-density DIN-rail or traditional panel mounts. Built with enhanced RFI/EMI immunity, it meets CE standards without special setup. SpringLoc terminals enable fast, tool-free wiring. Factory-calibrated for AISI 4140 steel (custom materials available).
Technical Data
- Brand: Bently Nevada
- Model: 330850-50–05
- Power: -17.5Vdc to -26Vdc (12mA max)
- Output: 50Ω resistance
- Range: -51°C to +100°C operation
Suffix Decoder: 330850-XX-YY
XX = Cable Length:
50 = 5.0m (16.4ft) system
YY = Certifications:
05 = Multi-agency approvals
Key Features
- Works with 3300 XL 25mm probes
- A380 aluminum housing
- Stainless steel mounting bracket
- 255g lightweight design
Installation Guide
Choose DIN-rail (high-density) or panel mount. Follow drawings 141092 (with barriers) or 140979 (without barriers).
Compatibility
Pairs with 3300 XL proximity probes & extension cables. Supports intrinsic safety barriers.
Compliance & Safety
- FCC Part 15
- EN 61000-6-2/4
- RoHS & EMC compliant
- ABS Maritime certified
Package Includes
- 1× Proximitor Sensor
- Installation manual
