Bently Nevada 3300 XL 11mm Proximity Probe: Precision Vibration Monitoring
Industrial-grade sensor for critical machinery health checks. Made in USA. COO available.
Key Features
- 11mm sensing diameter
- 1.0m cable with ClickLoc connector
- Extreme temperature range: -51°C to +177°C
- Viton O-ring pressure seal
- 12-month warranty
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL
- Full P/N: 330708-00-24-10-02-00
- Suffix Breakdown:
- 330708: 11mm Probe (5/8-18 UNF)
- 00: 0″ unthreaded length
- 24: 2.4″ case length
- 10: 1.0m cable
- 02: ClickLoc connector
- 00: No agency approval
- Core Data:
- Range: 0-2mm (typical)
- Resolution: 1µm
- Sensitivity: 200mV/mil
- Temp Range: -51°C to +177°C
- IP Rating: N/A (industrial housing)
- Resistance: 5.9Ω ±0.5Ω
- Materials:
- Tip: PPS polymer
- Case: 304 stainless steel
- Cable: FEP-insulated triaxial
Installation & Maintenance
- Torque Limits:
- Max: 45.2 N·m
- Recommended: 15.2 N·m
- Min bend radius: 25.4mm
- Do not expose below -34°C during install
- Calibrates with 3300 monitoring systems
Compatibility & Certifications
- Works with Bently Nevada 3300/3500 systems
- Certificate of Origin (COO) available
- CE/RoHS compliant
Package Details
- 1x Probe with connector
- Installation leaflet
- 12-month warranty
- Shipping: FedEx/UPS/DHL (2-5 days global)
Diagnostic Capabilities
- Detects unbalance/misalignment
- Identifies bearing defects
- Monitors radial shaft position
FAQ
- Pressure tested? No (custom option available)
- Cable lengths? 1m/5m/9m options
- Thread type? 5/8-18 UNF
- Warranty coverage? Manufacturing defects
Download Resources
Get full installation guides:
