330708-00-24-10-01-00 | Bently Nevada 3300 XL 11 mm Proximity Probe

Bently Nevada 330708-00-24-10-01-00 Proximity Probe: Precision Machinery Monitoring

New USA-made 3300 XL 11mm proximity probe for industrial diagnostics. Ships worldwide via FedEx, UPS, DHL with 12-month warranty.

Technical Specifications

• Brand: Bently Nevada
• Model: 330708-00-24-10-01-00
• Measurement Range: 11mm diameter
• Temperature Range: -51°C to +177°C
• Cable Length: 1.0 metre (3.3 ft)
• Thread Type: 5/8-18 UNF
• Resistance: 5.9 ± 0.5 ohms
• Cable Type: 75 Ω triaxial FEP
• Weight: 0.17 kg

Product Configuration

• Main Code: 330708
  • 3300 XL 11mm Probe
  • 5/8-18 UNF thread
• -00: 0″ Unthreaded Length
• -24: 2.4″ Case Length
• -10: 1.0m Cable
• -01: ClickLoc Connector
• -00: No Approvals Needed

Durability Features

• Case Material: AISI 304 stainless steel
• Seal Material: Viton O-ring
• Bend Radius: 25.4mm minimum
• Pressure Rated: Differential pressure sealing

Installation Guide

• Max thread engagement: 0.938″
• Recommended torque: 15.2 N•m
• Max connector torque: 0.565 N•m
• Avoid temperatures below -34°C during install

FAQ

• Q: What connector type is included?
  A: Miniature coaxial ClickLoc with protector
• Q: Is pressure testing included?
  A: Contact us for custom pressure testing
• Q: Minimum bend radius?
  A: 25.4mm (1.0 inch)
• Q: Cable insulation material?
  A: Fluoroethylene propylene (FEP)
• Q: Can I get Certificate of Origin?
  A: Yes, available upon request

Get Complete Documentation

Download full installation and specs:

• Download Probe Manual (PDF)
