330702-00-25-10-02-00 | Bently Nevada 11 mm Proximity Probe

Bently Nevada 3300 XL 11mm Short-Range Proximity Probe (330702-00-25-10-02-00)

Compact industrial sensor with 1-meter armored cable for space-constrained installations. Features stainless steel construction and high-temperature tolerance.

Critical Specifications

• Measurement Range: 0-2.5mm
• Accuracy: ±1.5% full scale
• Cable Resistance: 5.9Ω ±0.5Ω
• Case Length: 2.5 inches
• Thread Type: 1/2-20 UNF

Mechanical Design

Suffix Breakdown

• 330702 (Base Model)
  • 00: 0″ unthreaded length
  • 25: 2.5″ case length
  • 10: 1.0m cable
  • 02: ClickLoc connector
  • 00: No approvals

Installation Guidelines

• Max Torque: 45.2 N•m (400 in-lb)
• Recommended Torque: 15.2 N•m (133 in-lb)
• Min Bend Radius: 25.4mm (1.0in)
• Max Thread Engagement: 19.05mm (0.75in)

Temperature Performance

• Operating Range: -52°C to +177°C
• Storage Range: -52°C to +177°C
• Avoid below -34°C to prevent seal damage
• Pressure Seal: Viton O-ring (untested)

Package Contents

• 11mm proximity probe (1m cable)
• Miniature ClickLoc connector
• Installation guide
• 12-month warranty

Shipping Information

• Weight: 0.17kg
• Carriers: FedEx, UPS, DHL
• Origin: Made in USA

Technical FAQ

Q: Why choose 1m cable length?
A: Ideal for short-distance installations with minimal cable management needs.

Q: Can this probe measure non-metallic surfaces?
A: Optimized for conductive materials. For non-metals, consult factory for special calibration.

Q: Is the Viton seal suitable for chemical exposure?
A: Resists most oils and fuels, but verify compatibility for specific chemicals.

Q: What’s the advantage of 2.5″ case length?
A: Allows installation in space-limited mounting points where longer probes won’t fit.
