Bently Nevada Certified Proximity Probe – Industrial Grade Sensing
Complete Configuration Breakdown
- 330701: 3300 XL Probe Series
- 20: 2.0″ Unthreaded Length
- 30: 3.0″ Case Length
- 10: 1.0 Meter Cable
- 01: Connector Protector Included
- 05: Multiple Agency Approvals
Certified Specifications
- Electrical Resistance: 5.9Ω ±0.5 (1m cable)
- Thread Standard: 1/2-20 UNF
- Environmental Rating: -51°C to +177°C
- Sealing System: Viton O-ring
- Cable Type: 75Ω triaxial FEP
- Weight: 0.17kg
Premium Protection Package
- Connector protector for humid environments
- Global certifications for hazardous areas
- Extended 3″ case for deep installations
- PPS tip material for chemical resistance
- Stainless steel construction
Torque & Installation
| Installation Point | Recommended | Maximum |
| Probe Case | 15.2 N•m | 45.2 N•m |
| Connectors | Finger tight | 0.565 N•m |
Min Bend Radius: 25.4mm (1.0″)
Shipping & Support
- 12-month performance warranty
- FedEx/UPS/DHL express options
- Certificate of Origin available
- Made in USA quality assurance
Technical FAQ
Q: What approvals does “05” option include?
A: ATEX, IECEx, CSA, UL, CE certifications
Q: Why use connector protector?
A: Prevents moisture damage in humid environments
Q: Minimum safe temperature?
A: -34°C to prevent seal damage (avoid below)
Q: Pressure testing available?
A: Custom testing through our design department
Q: Shipping to hazardous locations?
A: Yes – certified for global hazardous areas
