330505-02-02-03 | Low Frequency Velocity Sensor Bently Nevada

Bently Nevada 330505-02-02-03 – 90° Side-Mount Vibration Sensor with 1/4-28 UNF Adapter

Key Benefits

• ⏹️ 330505-02-02-03 with 90° side mounting
• 🔩 Includes precision 1/4-28 UNF adapter
• 🛡️ Full 12-month protection
• 📦 Factory-sealed, ready to install

Technical Highlights

• ▸ Measures 0.5-1000 Hz vibrations
• ▸ 20 mV/mm/s sensitivity (±10%)
• ▸ Max speed: 4 in/s (102 mm/s)
• ▸ Works from -40°F to +212°F
• ▸ 100g shock resistance
• ▸ 1000ft cable capability

Model Number Explained

• 🔲 330505 – Base sensor model
• 🔲 -02 – 90°±5° side mount
• 🔲 -02 – 3/8-24 UNF thread
• 🔲 -03 – 1/4-28 UNF adapter

Installation Features

• ✔ 1/4-28 UNF fine thread option
• ✔ Max torque: 40 in-lb
• ✔ Stainless steel waterproof case
• ✔ Compatible with 3500/46M

Support & Shipping

• ✅ 1-year warranty coverage
• ✈ Fast global shipping: FedEx/UPS/DHL

Technical Questions

• Q: Why choose 1/4-28 UNF adapter?
  A: For precision equipment with fine thread requirements
• Q: How precise is side measurement?
  A: ±5° from perfect 90° position
• Q: Can I use this vertically?
  A: No, optimized for side mounting
• Q: What’s the housing rating?
  A: IP67 when properly installed
• Q: Is the adapter removable?
  A: Yes, reveals 3/8-24 UNF thread
